435Wp High-Efficiency Graphene PV Module
Features
• More Power per sq.ft.
• No Micro-crack Effect
• Less Impact On shading
Mechanical Parameters
Length: 67.80 in.
Thickness: 1.18 in.
Frame: Anodized Aluminium
Width: 44.65 in.
Weight: 46.30 Ibs.
Thermal Parameters
Temperature coefficient of power: -0.2755%/K
Temperature coefficient of current: 0.04725%/K
Temperature coefficient of voltage: -0.2375%/K
Nominal operating cell temperature: 109 36 F
Certifications & Warranty
Certification: IEC 61215
PID & LID Protection: 100%
Fire Resistance Rating: Type 2
Warranty: 30 Years
Performance Warranty: 0.2% Per Year
New Technology
The Graphene technology is a true breakthrough in
the construction of photovoltaic modules. The Graphene increases e ciency by up to 25%.
At the same time, it ensures long-term, trouble-free
operation – the product comes with an impressive
30-year warranty!
The modules degradation is only 0.2% per year,
marking yet another milestone in the field of
renewable energy.
Unique Features of Graphene
■ Transparent (absorbs only 2.3% of light)
■ Extremely strong (100–200 times stronger than steel)
■ Flexible (can stretch up to 20%)
■ Excellent thermal conductivity
– approximately 5000 W/mK
■ Very low electrical resistance
■ Very high electron mobility (200,000 cm²/V·s)
■ Incredible electron ow speed – (1/300) of the speed of light
Mechanical Parameters
Electrical Parameters
Cell: Mono 7.17 x 3.58 in
Cell: Mono 7.17 x 3.58 in
Coatings: 0.13 in anti-reflective coating ARC
Junction Box (J.Box): IP68, 3 diodes
Cable Length: Vertical -11.80 in; horizontal -47.20 in
Module Dimensions: 67.80 X 44.65 X 1.18 in
Open-circuit voltage (Voc): 38.40 V
Nominal power (Pnom): 410+ W
Graphene e ciency: 23.54%
Number of Cells: 108 (6 X 18)
Voltage at MPP: 32.20 V
Short-circuit current (Isc): 14.06 A
Maximum power (Pmax): 435+ W
Weight: 46.3 lbs
Frame: Anodized aluminum
Cable Cross-section: 4 mm
Connectors: MC4 or MC4 – compatible
